For extra support of heavy loads, this wall bracket attaches under the bottom edge of furniture or cabinet for perfect lift and leveling. Padded, swivel foot mount promises easy glide and a level surface.
Parts included: Plastic cover, black plastic cover, 4-taping screws, bolt, bolt plate, and stamping part.
P/N | SW-RHDLV-32 |
---|---|
Bracket Assemblies Per Pak | 4 |
Base Diameter | 1-1/4″ |
Thread Size | M10 |
Thread Length | 2.69″ |
Height Adjustment Range | 2-1/2″ |
Min Installation Height | 3″ |
Size For Adjustment at Top | 3/16″ |
Type of Tool for Top Adjustment | Allen |
Mounting Holes | 4 |
Hole Diameter | 0.19″ |
Black Plastic Cap for Leveler | Yes |
Mounting Fasteners Included | 4 |
Bracket Dimensions | 2.14″w x 2.15″h x 1.31″d |
Load Capacity | 100 lbs |
