Heavy-duty Corner Levelers

Attaches under edge and inside base wall of cabinet or furniture to supply invisible lift and leveling support with just four screws. Wide foot pad provides solid base of support for up to 330 lbs per four leveling mounts. Customized fit courtesy of simple allen wrench (not included).

Parts included: 4-taping screws, bolt, bolt plate, and stamping part.


P/N SW-RCL-12
Bracket Assemblies Per Pak 2
Base Diameter 2″
Thread Size M10
Thread Length 2.5″
Height Adjustment Range 1″
Min Installation Height 3″
Size For Adjustment at Top 3/16″
Type of Tool for Top Adjustment Allen
Mounting Holes 4
Hole Diameter 0.19″
Black Plastic Cap for Leveler No
Mounting Fasteners Included 4
Bracket Dimensions 4.93″w x 1.45″h x 1.97″d
Load Capacity 100 lbs
